CHAPTER 133
MANAGEMENT OF ACUTE AND CHRONIC OSTEOMYELITIS
Michael J. Patzakis
M. J. Patzakis: Department of Orthopaedic Surgery, University of Southern California School of Medicine, Los Angeles, California, 90033.
The portals of entry for osteomyelitis, or inflammation
of the bone, can result from hematogenous seeding, from direct
inoculation (i.e., following open fractures or open reduction and
internal fixation of fractures), or from the contiguous spread of
bacteria from infected structures. Early diagnosis and effective
surgical and antibiotic management can control the infection;
suppression of infection may last a lifetime.
Since the early 1980s, limb salvage with good functional
outcome has been enhanced by the addition of microvascular and local
muscle transfers, bone grafting techniques, bone transport for large
bone defects, newer antibiotics, and local antibiotic delivery systems.
The treatment of osteomyelitis requires the work of a team,

P.3534


consisting
of the orthopaedic surgeon, an infectious disease physician, and, in
complex cases involving soft-tissue defects or inadequate soft-tissue
coverage, a plastic surgeon. In many institutions, some orthopaedic
nurses are specially trained in the care of patients with orthopaedic
infections.

PATHOGENS
The organisms that cause osteomyelitis vary depending on
the portal of entry and the type, age, and associated medical
conditions of the host. Unfortunately, it is usually not possible to
accurately predict the specific pathogen on the basis of clinical
presentation alone. In the past, the most common causes of
osteomyelitis were Staphylococcus aureus and various streptococcal species. Gustilo et al. (22) and Patzakis et al. (48) reported that S. aureus
and coagulase-negative staphylococci were the most common organisms
causing infections in open fractures. However, the microbiology of
musculoskeletal sepsis has been changing in recent years. While S. aureus
remains the predominant cause of osteomyelitis, there has been an
increase in the frequency of infections caused by gram-negative
organisms (52,53).
The portal of entry is an important consideration in the
determination of the microbiology. Hematogenous osteomyelitis is most
commonly caused by S. aureus. In the past, Haemophilus influenzae type B (HiB) was a common organism in children, but the advent of HiB vaccine has made it a rare cause (3).
Causes of osteomyelitis due to direct inoculation, such as into an open
fracture, will be influenced by the environment in which the injury
occurred. For example, injuries occurring in water may lead to
infection with Aeromonas or Plesiomonas. Nail puncture wounds of the foot, particularly through a tennis shoe, are associated with infection with Pseudomonas aeruginosa (28,50).
Underlying medical conditions of the host also influence the expected microbiology. Intravenous drug users may have P. aeruginosa and other gram-negative bacilli as causes of their osteomyelitis (18,39,61). Patients with sickle cell disease are prone to the development of Salmonella
osteomyelitis. Osteomyelitis caused by fungal infections is more likely
to be seen in immunocompromised hosts. Diabetic foot infections leading
to osteomyelitis often are polymicrobial, often involving anaerobes and
gram-positive and gram-negative aerobic bacilli. Patients infected with
the human immunodeficiency virus (HIV) are at risk for a variety of
unusual infections, including atypical mycobacteria.
One of the greatest problems for the future is the
growing frequency of antimicrobial resistance in bacteria.
Methicillin-resistant S. aureus has been
known for decades, but its incidence is growing, even among
nonhospitalized patients. Multidrug-resistant gram-negative bacteria
are increasingly becoming a problem, limiting treatment options.
Vancomycin-resistant Enterococcus faecium
has become a major problem in nosocomial infections in the United
States, but thus far has been rarely seen in osteomyelitis. The
greatest concern is the development of vancomycin-resistant S. aureus,
which has now been identified in patients in Japan, the United States,
and Europe. Although this has not yet been reported as a cause of
osteomyelitis, bone infections with this organism could be
catastrophic, as no effective antibiotics for this infection are yet
available.
SYSTEMIC ANTIBIOTIC THERAPY
Antibiotic therapy is an adjunct to good surgical
management, which includes adequate debridement and wound management.
There has been a recent surge in the number of antibiotics available
for the treatment of osteomyelitis. The beta-lactam antibiotics, such
as penicillin and cephalosporin, are effective and relatively safe
antimicrobials that can cover a wide range of gram-positive and
gram-negative infections. The quinolones, however, have changed the
treatment of osteomyelitis by providing oral drugs that achieve
excellent serum levels and have good bone penetration.
The questions most often asked about the use of
antimicrobials concern the choice of agent, the optimal route
(intravenous, oral, or local), and the length of administration. The
Gram stain, culture, and antimicrobial sensitivity tests are important
guides in determining the specific antimicrobials to be used.
Sensitivity testing not only helps to identify resistant organisms but
also to guide the selection of the most active antimicrobial for the
specific infection.
Staphylococcus aureus
remains the most common cause of osteomyelitis. A semisynthetic
penicillin (such as nafcillin) is the drug of choice for most
staphylococcal infections. Alternative choices could include a
first-generation cephalosporin [such as cefazolin (Ancef)],
clindamycin, or a quinolone. Vancomycin is less active against S. aureus
than the penicillins and should not be used except in the case of
patient allergy to the beta-lactams or for the treatment of
methicillin-resistant S. aureus. Rifampin may be used in combination with one of the other agents for synergy.
Infections with the gram-negative bacilli can be treated
with a penicillin plus beta-lactamase inhibitor combination [such as
piperacillin-tazobactam (Zosyn)], a cephalosporin [such as cefotaxime
(Claforan) or ceftriaxone (Rocephin)], an aminoglycoside, or a
quinolone. For infections with P. aeruginosa,
treatment with an antipseudomonal beta-lactam (such as piperacillin,
ceftazidime, or cefipime) together with an aminoglycoside (such as
tobramycin,

P.3535



which is the most effective against Pseudomonas)
still represents the gold standard of therapy. Although successful
treatment with a single agent, such as ceftazidime, has been reported (1,16),
treatment failures with single-agent therapy have been noted, including
some cases associated with the emergence of resistance.

The quinolones are a major addition to the
antimicrobials available for the treatment of osteomyelitis. Currently
available quinolones that may be useful in the treatment of
osteomyelitis include ciprofloxacin, ofloxacin, and levofloxacin. They
have a broad spectrum of activity including S. aureus
and streptococci (with the newer quinolones such as levofloxacin having
much better activity against the gram-positive organisms than
ciprofloxacin), the aerobic gram-negative enteric bacilli, and P. aeruginosa.
One of the most important advantages of the quinolones
is the fact that oral administration results in levels similar to those
obtained with intravenous administration, suggesting that oral therapy
can replace intravenous therapy, at least in some instances (17,58).
Since the incidence of adverse reactions to these drugs is low, they
may be used in place of more toxic antimicrobials such as the
aminoglycosides.
The treatment of osteomyelitis caused by Mycobacterium tuberculosis
has been influenced by the rise in drug-resistant organisms. The
current treatment recommendations are starting with three or four drugs
(isoniazide, rifampin, pyrazinamide, and ethambutol), depending on the
level of isoniazide resistance in the community. If cultures show that
the organism is sensitive to isoniazide and rifampin, therapy can
continue with isoniazide and rifampin for a minimum of 6 months,
although longer regimens (9–12 months) are probably required (55).
Fungal infections have traditionally been treated with
amphotericin B, which was the only agent effective against deep fungal
infections. Although it is often effective, there are significant
adverse effects associated with the administration of amphotericin B,
including fever, chills, and nausea during administration, and renal
insufficiency or failure with potassium and magnesium wasting. Newer
agents such as fluconazole and itraconazole have excellent activity
against many of the fungal organisms and far fewer side effects.
Because of the large number of new antimicrobials
available, the problem of increasing resistance among organisms, and
the potential for significant adverse reactions with many of the drugs,
it is imperative that an infectious disease consultant help with the
selection of specific antibiotic therapy and the monitoring of the
patient for adverse reactions. Table 133.1 lists commonly used antimicrobials (also see Chapter 132).
Table 133.1. Commonly Administered Antimicrobials
TOPICAL ANTIBIOTIC THERAPY
Topical antibiotic therapy is an old concept.
Hippocrates and later Galen used medicinal ointments that included
honey, a bactericidal agent, in the treatment of open fractures. In the
early 1900s, Lord Lister, with good success, used phenol-soaked
compresses to combat the microorganisms believed to be responsible for
infection (35). He later introduced the use of
carbolic acid as an antiseptic. Following the discovery of the
sulfonamides, sulfa powder in wounds was popular among war surgeons.
The major

P.3536



changes of today are the choice of the agent used and the development of new vehicles for delivery.

Most orthopaedic surgeons use a topical antibiotic
solution for irrigation of infected wounds at the time of surgery.
Although any antimicrobial could be used, the most commonly used agents
are polymyxin (1 million units/L of saline) and bacitracin (50,000
units/L of saline).
Closed-suction antibiotic, high-volume irrigation
systems have been used for ingress and egress, usually administered for
a period of 3 to 21 days. The main deterrent to this mode of
administration has been the emergence of new organisms, usually
hydrophilic gram-negative organisms (10,29,47).
The overall success for antibiotic irrigation has been shown to be the
same as for antibiotic-impregnated polymethylmethacrylate (PMMA) beads (62).
Therefore, tube-suction irrigation has been abandoned by many surgeons.
If this system is used, adhere to every means possible to prevent
contamination. The risk of secondary contamination increases with the
length of usage of the irrigation system. It is advisable to use
Silastic drains and to place the tubes on suction or egress for 24
hours before removing the system. This procedure will remove all of the
fluid and hematoma present and will collapse the dead space, thereby
precluding the possibility of abscess formation. I do not recommend the
use of suction-irrigation systems.
Antibiotic-impregnated PMMA can be used to achieve local
delivery of high concentrations of antibiotics. Among the advantages of
antibiotic beads are low systemic levels of antibiotics, resulting in a
lower potential of systemic toxicity, decreased need for systemic
intravenous therapy, and decreased length of hospital stay. The
disadvantages are that it requires a closed wound for the development
of high local levels of antibiotics. Moreover, it may act as a foreign
body, especially in the presence of resistance to the antibiotic in the
vehicle, such as gentamicin or tobramycin.
The use of antibiotic-impregnated PMMA in total hip implants has been advocated (4,5,41).
Klemm and other investigators have reported good results with the use
of gentamicin-impregnated methylmethacrylate beads (Septopal) for the
treatment of chronic osteomyelitis (30,31).
Unfortunately, the United States Food and Drug Administration (FDA)
approval of factory-made gentamicin beads (Septopal) has been
indefinitely delayed, leading many surgeons to make their own beads
using bead molds (13).
Numerous studies have evaluated the in vitro elution characteristics of PMMA combined with antibiotics. The

P.3537



majority of studies have evaluated gentamicin, but as it is no longer
commercially available in powder form for injection in the United
States, physicians now use tobramycin and vancomycin since they are
active against the most common organisms leading to prosthetic joint
infections and osteomyelitis. Antibiotic elution from
antibiotic-impregnated PMMA is proportional to the surface area of the
cement (68,69)
and affected by the type and concentration of the antibiotic used, the
brand of PMMA cement, and the amount and turnover of the surrounding
fluid (66). Studies have shown that antibiotics
elute better from beads than from spacers, and better from palacos
cement than from simplex cement, and tobramycin achieves better levels
than vancomycin (20,33,36).

Overall, the results of treatment with
antibiotic-impregnated PMMA beads are encouraging, so the use of these
in selected cases seems appropriate (Fig. 133.1).
A different vehicle for the delivery of local antibiotic therapy may
improve results and lessen the disadvantages associated with this
therapy. Various biodegradable antibiotic delivery systems are now
being evaluated but are still in the investigational stage.
Figure 133.1.
Anteroposterior roentgenograms of a 46-year-old man with chronic
osteomyelitis. The patient was treated with debridement followed by
insertion of aminoglycoside-impregnated methylmethacrylate beads and a
local muscle flap.
CLASSIFICATION OF OSTEOMYELITIS
Cierney et al. proposed a staging system for adult osteomyelitis based on anatomic type and physiologic class (7,8).
The four anatomic types are type I, medullary osteomyelitis; type II,
superficial osteomyelitis; type III, localized osteomyelitis; and type
IV, diffuse osteomyelitis.
The three physiologic classes deal with the condition of
the host. An “A” host has good systemic defenses with good local
vascularity and a normal physiologic response to infection and surgery.
A “B” host is a compromised host with either local, systemic, or
combined deficiency in wound healing and infection response. A “C” host
is a patient who is not a surgical candidate, requires suppressive or
no treatment, who has minimal disability, or for whom the treatment or
results of treatment are more compromising than the disability caused
by the disease itself.
DIAGNOSIS
A diagnosis of acute osteomyelitis should be considered
an emergency. The presenting signs and symptoms may vary with the
severity of the infection. Symptoms include fever and chills, general
malaise, irritability, pain, and swelling. With lower extremity
involvement, there is either a limp or an inability to bear weight. An
infant with upper extremity involvement may exhibit pseudoparalysis;
older children and adults with upper extremity involvement complain of
pain on movement or use of the extremity.
It is important to localize the point of maximum
tenderness, which is usually warm and swollen. In children it is
generally in the metaphyseal region. It is also important to evaluate
the adjoining joint for evidence of septic arthritis, which can occur
as an extension of the adjoining osteomyelitis. Osteomyelitis involving
the neck of the femur, talus, and humeral head often leads to sepsis of
the joint because these foci are located within the joint capsule.
Once the point of maximum tenderness is localized,
aspirate the area, and send the pus or fluid obtained for Gram stain,
culture, and sensitivity studies. If tuberculosis or a fungal infection
is suspected, obtain an acid-fast stain and tuberculosis and fungal
cultures. When a joint effusion is present or joint involvement is
suspected, aspirate the joint and confirm with an arthrogram. The
arthrogram helps document the location of the aspiration and is useful
for positive as well as for negative aspirations, since it may also
identify joint capsule rupture. Aspiration of the hip joint under
ultrasound guidance is very helpful in children and adults.
The white blood cell count is generally elevated,
depending on the severity of the infection, with an increase in
immature or band cells. The erythrocyte sedimentation rate and the
C-reactive protein are usually elevated. Obtain blood cultures in all
cases of acute hematogenous osteomyelitis and in chronic osteomyelitis
exacerbated by fever and bacteremia.
Roentgenograms taken early in the disease process
generally show soft-tissue swelling. Bony changes are not present until
7–10 days after the onset of infection. Radionuclide bone scanning
using radioactive-labeled isotopes, such as technetium-99m and, more
specifically, gallium citrate-67 and indium-111-labeled white blood
cells, is helpful in localizing the area of involvement and in helping
diagnose the condition.
Plain technetium, sequential technetium-gallium imaging,
and indium-labeled leukocyte scintigraphy are the studies most commonly
used. Indium 111-labeled leukocytes have been reported by a number of
investigators as being more useful than other imaging in osteomyelitis
complicated by fractures and nonunions (11,38,40,63) (see Chapter 132).
Aspiration is used for the diagnosis, especially when there is no
drainage or sinuses, and in some cases bone biopsy may be necessary.
Magnetic resonance imaging (MRI) has added a new
dimension to the diagnosis, localization, and characterization of the
extent of infection. MRI has been reported by Modic et al. to have a
94% accuracy in diagnosing spine infections (40).
T1- and T2-weighted images are the initial screening techniques for
diagnosing osteomyelitis. The MR finding in osteomyelitis on
T1-weighted image sequences is a low signal intensity due to a dark
marrow signal and an increased signal intensity due to a bright marrow
signal on the T2-weighted image sequences (Fig. 133.2, Fig. 133.3).

P.3538



MRI has decreased the need for bone scanning and provides more useful
information. Do sinograms whenever there is a sinus tract or open
draining area from which the depth and extent of the infection can be
determined (Fig. 133.4).
Do abscessograms whenever an abscess is present and frank pus is
aspirated. The abscessogram will help outline the extent of the abscess
cavity (Fig. 133.5). MRI, computed tomographic scanning, and radiographic tomogram are all useful tools in evaluating osteomyelitis.

Figure 133.2.
These are T1-weighted images of a 44-year-old woman with systemic lupus
erythematosis and hematogenous osteomyelitis. There is decreased signal
within the distal third of the tibia and a serpiginous area of low
intensity consistent with osteonecrosis. A biopsy had been performed
previously. At surgery, she had an abscess with sequestra.
Figure 133.3.
These T2-weighted images of a 15-year-old boy show increased signal
from the ankle to the mid tibia. There is increased signal in the
adjacent soft tissues about the ankle and tibia. There is a minimal
ankle effusion present. At surgery, the patient had an intramedullary
abscess of the metaphysis and distal tibia.
Figure 133.4. Anterior (A) and posterior (B) roentgenograms of a sinogram in a 21-year-old man with chronic osteomyelitis that tracks into the intramedullary cavity.
Figure 133.5. Lateral radiograph (A) of a 15-year-old boy shows a subperiosteal abscess that was aspirated and injected with contrast material. Anteroposterior (B) and lateral (C)
radiographs of a 9-year-old child show contrast material in the
subperiosteal area and within the medullary cavity after pus had been
aspirated. The contrast material demonstrates the extent of the abscess.

P.3539



P.3540


PRINCIPLES OF TREATMENT OF INFECTED UNUNITED FRACTURES AND NONUNIONS
The principles of treatment are infection control,
stabilization of the fracture, soft-tissue coverage, and bone graft of
ununited fractures and large bone defects.
Infection control includes irrigation and debridement,
culture and sensitivities, and antibiotic therapy. In chronic
osteomyelitis, obtain aerobic, anaerobic, and fungal cultures. Recent
studies have advocated taking of multiple deep cultures from purulent
material, soft tissue, and bone (51,56).
Marrie and Costerton postulated that different organisms may be growing
in isolated microenvironments. Sampling differences and bacterial
viability may influence the culture results (37).
Stabilization of the ununited fracture or nonunion is
essential. Soft-tissue coverage may require the use of local muscle
flaps and free vascularized muscle flaps for soft-tissue defects or an
inadequate soft-tissue envelope after control of the osteomyelitis.
Local muscle flaps and free vascularized muscle transfers also help by
bringing in a new blood supply, which is important in host defense
mechanisms, antibiotic delivery, and osseous and soft-tissue healing (46).
For the tibia, use the gastrocnemius muscle for proximal-third defects,
the soleus for middle-third, and for the distal-third, free
vascularized muscle transfers.
For local muscle transfers, it is important to assess
the muscle preoperatively and not to transfer damaged muscle. Also
avoid using crushed or badly damaged muscle, as flap necrosis or flap
complications may result. In these cases, use free vascularized tissue
transfer. Do preoperative angiograms on patients whose vascular status
has been altered from any cause.
SURGICAL CONSIDERATIONS
TOURNIQUETS
Apply a tourniquet whenever possible except in patients
with sickle cell disease or significant peripheral vascular disease.
The tourniquet improves hemostasis and thus facilitates identification
of the infection process. In acute cases with swelling, cellulitis, or
abscess formation, elevate the extremity for several minutes before
inflating the tourniquet. In chronic osteomyelitis without significant
cellulitis or abscess formation, use an elastic bandage to extravasate
the extremity before inflating the tourniquet.
DEBRIDEMENT
Thorough debridement of all sequestra and necrotic and
desiccated bone is essential. Do not remove viable infected bone, so as
not to create large bony defects. It is not necessary to debride viable
infected bone. Dyes and tetracycline labeling have been used as a means
of identifying necrotic bone, but I have not found these techniques to
be useful.
Clinically dried out, exposed, desiccated bone is darker
than normal and should be debrided. Necrotic bone that has not been
exposed may appear at surgery more yellowish than viable bone, which is
whitish. The main finding is that viable bone bleeds, whereas necrotic
bone does not.
Use of an osteotome to superficially shave the outer
cortex of the questionable bone results in small areas of punctate
bleeding. Some bone that may have been exposed to air may be viable; in
these cases, the exposed outer cortex should be debrided with an
osteotome down to good bleeding bone. Evacuate all pus and abscess, and
remove all necrotic and infected soft tissue.
IRRIGATION
Use copious amounts of irrigating fluid, which cleanses
the area of purulent exudate, loose soft tissue, and bony fragments,
and decreases the bacterial count. I use 10 L of irrigating fluid for
most infected wounds. I use 2 L of antibiotic solution containing
50,000 units of bacitracin and 1 million units of polymyxin per liter
as the final irrigating solution. Other antibiotics can be used for
topical irrigation as well.
WOUND MANAGEMENT
The decision to leave a wound open or to close it
requires careful judgment. In the majority of acute infections, and in
all cases in which there is associated abscess formation with
cellulitis and swelling, the wound should be left open. In some cases
of early postoperative infection, the wound may be closed over drainage
tubes, as long as the wound is thoroughly clean and the infection is
not anaerobic.
In cases of chronic osteomyelitis in which there is no
significant cellulitis or abscess formation and in which the wound has
been adequately debrided and converted to a clean wound, the wound may
be closed over drainage tubes. In some cases in which bone or metal
will be exposed if the wound is left open, a partial closure over the
bone or metal may be desirable, as long as an adequate pathway has been
provided for drainage. When there is any doubt, it is safest to leave
the wound open. If the wound is closed, the wound site must be examined
daily for any signs of infection; if such signs appear, the wound must
be opened.
Many wounds heal nicely by secondary intention. In the
case of large wounds or when delayed closure is preferable, do not
attempt closure until two criteria are met. First, the wound should
appear clinically healthy, with clean granulating tissue and without
any purulent exudate or necrotic tissue. If infected necrotic tissues
are present, redebride the wound until it appears healthy. Second, once

P.3541


the
clinical appearance of the wound is clean, take quantitative tissue
cultures and do Gram stains. Wounds with either a positive Gram stain
or quantitative tissue cultures with a bacterial count greater than 10-5 organisms should never be closed. (A positive Gram stain implies a bacterial count of greater than 10-5 organisms.)

These wounds should be considered infected and
reassessed for further surgical debridement and the appropriateness of
the systemic antibiotic therapy. With experienced surgical teams,
tissue cultures are not routinely performed. It has been our practice
to do a thorough initial debridement followed by an en bloc excision of the wound at closure or muscle transfer.
In secondary closure of wounds, it is important to redebride the wound at the time of closure and to do en bloc
resection of the granulating tissue for several reasons. First,
although the bacterial count is low, these tissues should still be
considered contaminated; debridement will further reduce the bacterial
count and thereby diminish the chance of infection. Second, debridement
allows for cleaner, healthier tissue to be approximated by wound
closure or covered by muscle transfer.
DRAINS
When the wounds are closed, Silastic (Jackson-Pratt) or
polyethylene (Hemovac) drains may be used. I prefer the Jackson-Pratt
drains. Penrose drains, made of rubber, are the most reactive, and if
left in for long periods can cause foreign-body granulomas. Do not use
Penrose drains in orthopaedic infection management.
Remove the suction drain in 48–72 hours. The drain
allows the removal of all hematoma and tissue fluid, and the collapse
of the potential dead space. The drains should be removed under sterile
conditions and the tip cut off and sent for culture and sensitivity
tests.
The drain tends to attract whatever bacteria are present
because it is a foreign body and because tissue fluids are removed
through it. In general, a positive culture of the drain tip is a bad
prognostic sign: It means that bacteria remain behind. Monitor the
clinical course and wound site closely; if any clinical signs of wound
infection reappear, it may be necessary to consider redebridement and
reassessment of antibiotic therapy.
WOUND PACKING
The purpose of leaving a wound open is to allow
drainage. Make certain, therefore, when packing wounds with gauze or
other materials, that packing does not obstruct drainage. If it does,
the purulent exudate will be retained in the wound, possibly causing
tissue breakdown and necrosis with secondary cellulitis or even abscess
formation. It is best to put wicks perpendicular to the open wound to
allow free drainage. Wicks can be either povidone-iodine
(Betadine)-soaked gauze, plain gauze, or fine-mesh gauze. The size
varies with the size of the wound. The ends of the wicks should always
protrude through the skin edges to allow easy access and removal and to
prevent retention.
ANTIBIOTIC BEAD POUCH
Antibiotic-loaded beads were first introduced by Klaus Klemm for use in osteomyelitis (30,31). Henry, Seligson, and Ostermann introduced a physician-made antibiotic bead pouch for use in open fractures (25,43).
This concept has been expanded, and I now use a physician-made
antibiotic bead pouch during the interval between the initial
debridement and the time of muscle transfer, a median of 4 days.
Microbe-specific antibiotic(s) can be added to either Palacos or
Simplex PMMA. I prefer Palacos: The antibiotic elution has been
reported by some investigators to be better them Simplex. Although most
antibiotics may be added to PMMA depending on the microbial sensitivity
results, tobramycin and other aminoglycosides are the most commonly
used antibiotics.
I use 2.4 g tobramycin to 40 g Palacos PMMA, an amount
sufficient to make enough bead chains to fill large defects. I use a
mold to make 6- or 7-mm beads strung on 24- or 26-mm wire. For those
surgeons who make beads without a mold, the bead size should be small
because increased surface area allows for better antibiotic elution.
The beads are then covered by Tegaderm, Opsite, or an equivalent
material. The advantages of the antibiotic bead pouch used in this
fashion are high local antibiotic levels with low systemic toxicity and
less chance for secondary contamination because the wound is covered.
Also important is patient comfort, as dressing changes are not
required, and there are decreased requirements for wound care.
SURGICAL TECHNIQUES
HEMATOGENOUS OSTEOMYELITIS
Hematogenous osteomyelitis is most often seen in
infants, children, drug abusers, and immunosuppressed hosts. In 1894,
Lexer injected laboratory animals with S. aureus organisms and then traumatized a bony area, causing infection to appear at that site (34).
Hobo explained that the predilection for the metaphysis in acute
osteomyelitis was due to the fact that the arteries in this location
are end arteries, that there is slowing of the venous flow in the
sinusoids, and that phagocytosis is defective in this area (27).
Trueta later expanded on Hobo’s work (65). Once the metaphyseal region is seeded and exudate or pus forms, the suppurative process may then travel under pressure

P.3542



through the Volkmann canals into the subperiosteal region, extend
itself within the medullary cavity, or spread into the epiphysis (Fig. 133.6).
It is not uncommon for the joint to be involved secondarily, especially
a joint in which the metaphysis is intra-articular, such as the hip or
shoulder. Often the abscess extends into the soft tissues as well (42,67).

Figure 133.6.
Outline of the pathophysiology of hematogenous seeding. When under
pressure, the exudate or abscess can extend through the Volkmann canals
into the subperiosteal region, and from there into the intramedullary
cavity or the epiphysis. (Modified from Hobo T. Zur Pathogenese der
Akuten Haematogene Osteomyelitis, mit Berucksichtigung der
Vitalfarbungslehre. Acta Sch Med Univ Imper Kioto 1921;4:1.)
In cases in which the disease is not diagnosed promptly
or in which either inadequate or no treatment is given, the disease
enters the subacute stage (Fig. 133.7). Because
of the introduction of antibiotics and improved diagnostic and surgical
techniques, the chronic stage and its sequelae are no longer seen as
frequently as they used to be.
Figure 133.7. A: A frog-leg lateral view shows a lytic area in the metaphysis of a 7-year-old boy with a 6-month history of pain and a limp. B: Anteroposterior radiograph taken at the time of biopsy. The lesion was found to be a subacute osteomyelitis caused by a Staphylococcus aureus organism.
One question that arises in the treatment of acute
hematogenous osteomyelitis is whether to treat all patients surgically.
Unless clinical evidence of an abscess is present, I treat patients
with systemic antibiotics and without surgery. However, the clinical
situation must be repeatedly assessed during treatment. Many
osteomyelitic processes are seen early in the disease process or
represent a cellulitic process of the bone, and pus or the abscess
phase may not occur.
Although some authors have not found it necessary to
drill a window in cases of subperiosteal or soft-tissue-extended
osteomyelitis, I routinely window the cortical bone for better
debridement of the residual intramedullary abscess and necrotic bone
and tissue (Fig. 133.8) (see Chapter 176).
Figure 133.8. A: Anteroposterior radiograph in a child shows destructive lytic changes in the metaphyseal region with periosteal reaction. B: Lateral film shows the extent of the cortical window made for debridement of the medullary abscess. C: Lateral film taken 7 months later shows healing of both the cortical window and the osteomyelitic process.
Cortical Windowing for an Acute Intramedullary Abscess of the Tibia
  • Using tourniquet control, make a
    longitudinal incision along the posterior border of the medial tibia
    and over the affected part of the tibia. If a subperiosteal abscess is
    present (more likely in a child than in an adult), incise the
    periosteum longitudinally over the abscess.
  • If no subperiosteal abscess is found,
    observe the status of the cortex. The infected area is often soft and
    may be pitted, with or without obvious cortical destruction.
  • Drill several holes through the cortex into the medullary

    P.3543



    canal. Unless the intramedullary abscess has already decompressed
    itself into the subperiosteum or soft tissues, pus will exude through
    these holes.

  • Outline with a drill an elongated
    cortical window extending along the extent of the intramedullary
    abscess. The outlined elongated window should be centered in the
    posterior half of the anteroposterior diameter of the bone to allow for
    dependent drainage. The length of the window depends on the extent of
    the intramedullary abscess, and the width depends on the diameter of
    the bone. For children, use a 1- to 2-cm-wide window. After debridement
    of any obvious sequestrum and copious irrigation, insert a Betadine
    gauze into the wound and leave it open. A similar type of window of the
    femur is made for osteomyelitis of the femur.
OSTEOMYELITIS FOLLOWING OPEN FRACTURES
For acute osteomyelitis following an open fracture, it
is important to assess the extent of the infection and to obtain a Gram
stain, culture, and sensitivity test. Start appropriate systemic
antibiotics, and take the patient to surgery for irrigation,
debridement, and stabilization of the fracture if it is not already
adequately stabilized (Fig. 133.9). The
majority of fractures in the tibia can be stabilized with half-pin
external fixation devices. Use a biplanar or delta frame for more
stability if required.
Figure 133.9. A: A 28-year-old man with an infected open fracture. B:
There is a clean granulating wound 12 days after the fracture had been
irrigated, debrided, and stabilized with an external fixator and the
patient given systemic antibiotic. At this time, biplanar fixation with
half-pins rather than full-length pins would be performed.
Once the open fracture infection has been controlled and
the fracture stabilized, perform cancellous autogenous bone grafting,
particularly for fractures with bone deficiency and type III open
fractures. Fracture healing, which facilitates infection control, is an
important principle in the management of infected nonunited fractures
and nonunions. Although many fractures heal in the presence of
infection, infection interferes with the osteogenic process and may
lead to nonunion by a number of mechanisms: The bacteria compete with
osteogenic cells for oxygen and nutrients, activate enzymes deleterious
to the osteogenic process, lower the pH, affect oxygen potential,
interfere with the differentiation of osteogenic cells, and retard
tissue maturation.
For both unstable infected open tibial fractures and
type III infected open tibial fractures, I recommend early autogenous
cancellous bone grafting through a posterolateral approach.
Alternatively, if a muscle flap has been made anteriorly for
soft-tissue coverage, an autogenous

P.3544



cancellous bone graft can be done anteriorly 6 weeks later, provided there is no evidence of recurrent infection.

Posterolateral Bone Grafting of the Tibia
Posterolateral bone grafting is particularly useful in
achieving union of an infected nonunion or an infected fracture of the
tibia. Freeland and Mutz have reported a 100% union rate in 26 patients
with infected nonunions treated in this manner (14). I have achieved a union rate of approximately 91% in the treatment of 61 infected tibial nonunions (49).
The approach is used for the distal two thirds of the
tibia. It was described by Harmon and is also used for tibia-pro-fibula
grafting (23) (Also, see Chapter 3).
  • Place the patient in either a prone or a
    lateral decubitus position. Identify the posterior border of the fibula
    and the lateral border of the gastrocnemius muscle. Using tourniquet
    control, begin an incision of appropriate length along the lateral
    border of the gastrocnemius and posterior to the fibula.
  • Once you have cut through the
    subcutaneous structure, identify the peroneal muscles anteriorly and
    develop a plane between the peroneals and the posterior muscles

    P.3545



    consisting of the gastrocnemius, the soleus, and the flexor hallucis longus muscles.

  • Now reflect the soleus and flexor hallucis longus posteriorly and medially to expose the posterior aspect of the fibula.
  • Elevate the origin of the tibialis
    posterior muscle from the posterior aspect of the interosseous
    membrane. Locate the posterolateral border of the tibia and, using
    sharp dissection, expose the posterior surface of the tibia by
    stripping the muscles subperiosteally off the tibia. In the distal one
    third of the tibia, approximately four to five fingerbreadths above the
    tip of the lateral malleolus, an interosseous arteriole branch from the
    peroneal artery perforates the interosseous membrane and travels
    anteriorly to anastomose with the anterior tibial artery. Take care to
    protect this vessel. The posterior tibial neurovascular bundles lie
    between the tibialis posterior and flexor hallucis longus muscles and
    are not visible. The muscular branches of the peroneal artery lie
    within the peroneal muscles.
  • Once the posterior aspect of the tibia is exposed (Fig. 133.10),
    prepare the tibia and the posterior aspect of the fibula for bone
    grafting by roughening up the cortex with either a burr or an
    osteotome. Be extremely careful not to disturb the fracture site so as
    to avoid contamination posteriorly.
    Figure 133.10. A:
    A cadaveric specimen outlining the fibula. A skin incision varying with
    the exposure desired is made just posterior to the fibula along the
    lateral border of the gastrocnemius and soleus muscles. B,C:
    The peroneal muscles are retracted anteriorly and the border of the
    fibula is exposed. The tibialis posterior and the flexor hallucis
    muscles are dissected from the interosseus membrane and the posterior
    tibia and retracted posteriorly. The posterior tibialis neurovascular
    bundle is protected by the tibialis posterior and flexor hallucis
    longus muscles, which it lies between. D:
    The posterior aspect of the fibula is now exposed, and the posterior
    border of the fibula and interosseous membranes are visible.
  • Lay cancellous bone grafts posteriorly
    several inches above and below the fracture site and between the tibia
    and fibula across the interosseous membrane. The objective is to
    achieve not only union of the fracture site, but also a tibial–fibular
    synostosis (Fig. 133.11). A 1.5–2 oz medicine glass filled with cancellous bone is generally sufficient to repair a nonunion without bone loss.
    Figure 133.11.
    Anteroposterior and lateral films show healing of the fracture
    following the posterolateral bone graft. Note the synostosis between
    the tibia and fibula.
  • At this point, release the tourniquet and
    achieve hemostasis. Insert a Silastic drain. Allow the peroneal muscles
    and posterior muscle mass to return to their anatomic positions. Do not
    close the deep fascia.
  • Close the subcutaneous tissues and skin with interrupted sutures.
  • P.3546


  • Remove the Silastic drains in approximately 48 hours and elevate the leg for 72 hours.
  • Start full weight bearing to tolerance 7 days postoperatively if the patient is immobilized in a cast.
  • If an external fixator is used for an unstable fracture, it can generally be removed at 6–8 weeks and a walking cast applied.
  • Union generally occurs in 4–7 months, median time being 6 months.
DEAD-SPACE MANAGEMENT
It is important that soft-tissue and bony defects be
filled to reduce the chance of continued infection and loss of
function. Advances in microvascular techniques have made possible the
transfer of muscle, myocutaneous, osseous, and osteocutaneous flaps to
the soft-tissue and bony defects. Fitzgerald et al. reported a 93%
success rate in the treatment of chronic osteomyelitis with local
muscle flaps combined with thorough debridement and specific
antimicrobial therapy (12). Our results using this technique have also been encouraging (46).
In general, for soft-tissue defects involving the
proximal third of the tibia, use the gastrocnemius muscle; for those
involving the middle third, use the soleus muscle; and for those
involving the distal third, use a free-tissue transfer.
In cases of bony defects, perform autogenous cancellous
bone grafting six or more weeks later. The muscle flap can be elevated
and cancellous bone grafting performed underneath, provided there are
no signs of infection (Fig. 133.12).
Figure 133.12. Anteroposterior (A) and lateral (B)
radiographs of the tibia and fibula in a 21-year-old man who had a
previous posterior bone graft and now shows the presence of a large
sequestrum. Lateral film (C) shows debridement of the infection and sequestra. Lateral film (D) taken 10 months after a local flap was performed and an autogenous cancellous bone graft was performed.
According to Weiland et al., the highest rate of
recurrence of infection in free-tissue transfer in osteomyelitis is
found in cases associated with a segmental bone defect (70).
It has been our experience that the fibula is the key factor in
treating osteomyelitis with segmental bone loss of the tibia. If there
is a bony defect or segmental loss of both the fibula and tibia with
chronic osteomyelitis, an amputation is advisable. If the fibula is
intact or without a bony defect, reconstruction of the bony defect is
more likely to be successful. For defects up to 6 cm, autogenous
cancellous bone grafting can be done (Fig. 133.13).
Figure 133.13. A: Anteroposterior radiograph of a 34-year-old woman with approximately a 6 cm defect. B:
Anteroposterior and lateral films taken 1 year following performance of
an autogenous cancellous bone graft to fill dead space caused by bony
defects.
In larger defects, use a free vascularized osseous
graft. A tibia-pro-fibula synostosis using the previously described
posterolateral approach can be done when a free vascularized osseous
graft or autogenous cancellous bone grafting of the defect is not
possible (Fig. 133.14). The fibula hypertrophies with time, allowing for functional weight bearing.
Figure 133.14. A:
Anteroposterior and lateral radiographs of a 48-year-old man who
developed clostridial myonecrosis after an open fracture of the tibia
and treatment with a tibia-pro-fibula synostosis. The distal synostosis
site was bone grafted first and is seen here 10 weeks postoperatively. B:
Radiographs taken 4 years after the tibia-pro-fibula synostosis for the
segmental defect. Note the synostosis proximally and distally, and the
hypertrophy of the fibula. C: Healed wounds show no evidence of recurrence of infection. Notice the area of defect in the middle calf area.
Another procedure for dead-space management is the open cancellous bone grafting procedure described by Rhinelander (57) and by Papineau et al. (45). This procedure is useful when tissue transfer is not possible.
Open Cancellous Bone Grafting
Open cancellous bone grafting has been effective in the treatment of infected bone defects. Papineau et al. (45), Roy-Camille et al. (59,60), Rhinelander (57), Higgs (26), Knight and Wood (32), Coleman et al. (9), Bickel et al. (2), and Green and Dlabal (19)
have all reported favorable results. However, because of the associated
long hospitalization time, long healing time, high complication rate,
meticulous care required, and resulting unstable scar skin, I use it
only if local muscle transfers or free-vascular tissue transfers with
secondary cancellous bone grafting cannot be done.

P.3547



P.3548


There are three stages to this technique:
  • Thorough debridement of all infected
    tissues, repeated as necessary; stabilization of the fracture with an
    external skeletal fixator
  • Cancellous autogenous bone grafting into a defect lined with clean uninfected granulation tissue
  • Skin coverage either by secondary epithelialization or, in larger defects, by split-thickness skin grafting
  • Debride all infected soft tissue and
    sequestra, and debride all necrotic bone to bleeding osseous tissue.
    Perform stabilization using an external skeletal fixator.
  • When exposed surfaces are covered with
    clean granulation tissue, pack finely morcelized autogenous cancellous
    bone into the defect created by the bone debridement or previous bone
    loss. The diameter of the graft should be slightly larger than the
    diameter of the bone being replaced, since the graft will tend to
    contract. Rhinelander recommends that the maximum graft thickness be
    1.5 cm from the nearest granulation surface (57).
  • Dress the wound with gauze and keep it
    moist with a physiologic irrigating solution such as Ringer’s lactate,
    either by intermittent soaking of the dressings or by a slow
    intravenous drip. The dressing, which should be changed daily, is to be
    soaked with physiologic solution until the wound is covered by
    epithelialization or, in some cases, by secondary split-thickness skin
    grafting (Fig. 133.15).
    Figure 133.15. A:
    Lateral radiograph of the tibia and fibula in a 37-year-old woman with
    loss of the tibia following an infection that developed after the
    patient sustained a type III open fracture. B: Anteroposterior photograph shows the soft-tissue and bone loss and exposed tibial shaft. C: Photograph taken at the time of autogenous cancellous bone grafting of the dead space. D,E: Anteroposterior and lateral radiographs, taken after the grafts had consolidated, show healing of the fracture. F:
    Lateral photograph, taken 3 years after the procedure, shows knee
    flexion and the appearance of the leg. The patient has been free of
    infection.

P.3549



P.3550


OSTEOMYELITIS IN THE PRESENCE OF INTERNAL FIXATION FOR FRACTURE STABILIZATION
Osteomyelitis in conjunction with internal fixation for
fracture stabilization poses a special problem for the surgeon. Should
the metal be removed or left in? The answer to this question is guided
by such factors as the stage of fracture healing, the amount of
stability provided, the amount of time since surgery, and the location
of the fracture.
Gristina and Costerton reported that in 76% of
prosthesis-related infections, microorganisms grew in a biofilm or
glycocalyx that adhered to the surfaces of the biomaterials present (21).
They suggested that infections in the presence of orthopaedic implants
may be more resistant than normal to host defense mechanisms and to
antimicrobial therapy.
If osteomyelitis develops in the presence of metal with
a healed fracture, remove the metal. If the fracture is not united and
the metal is not providing stability, remove the metal and restabilize
the fracture. In the immediate

P.3551



postoperative period (within the first 1–6 weeks), retain the internal fixation device if it is stable and is required.

If the internal fixation device is stabilizing a nonunited articular fracture, retain it (Fig. 133.16).
In general, for late infected nonunion of tibial shaft fractures with
internal fixation, I recommend removal of the internal fixation device
and stabilization with an external fixator. For late nonunion
infections of the femur with plate fixation, I recommend removal of the
plate and eventual stabilization with an intramedullary rod.
Figure 133.16. A: Anteroposterior radiograph of the distal tibia and fibula showing a comminuted fracture of the tibia and plafond. B,C:
Anteroposterior and lateral films taken following open reduction and
internal fixation show fractures nonunited at the time of infection. D:
Anterior photograph of the ankle shows exposed metal and ankle joint
with a necrotic anterior tibialis tendon after an acute postoperative
infection. E: There is no evidence of infection 9 months following removal of metal and a free-vascularized latissimus dorsi muscle transfer.
In femoral infections with intramedullary rods, an exchange rodding is preferred. If an extensive intramedullary

P.3552



abscess with cellulitis is present, it may be necessary to insert
antibiotic beads into the medullary canal, treat the patient in
traction for several days, and then redebride the femur and stabilize
the fracture with an intramedullary locked nail. I prefer
intramedullary nail stabilization over external fixation in most cases
because of the propensity for pin loosening, infections, and binding
down of muscles with external fixation.

At the time of debridement, it is important to remove
the infected membrane from within the canal by reaming followed by
copious pulsatile irrigation. In the case of infected intramedullary
nails involving the femoral shaft (unless there is an extensive
associated intramedullary abscess), the metal does not adversely affect
eradication of the infection, provided the infection has been
appropriately treated with surgical debridement and parenteral
antibiotics followed by fracture healing with or without autogenous
cancellous bone grafting (54).
OSTEOMYELITIS OF THE METATARSAL HEADS AND PHALANGES FOLLOWING PUNCTURE WOUNDS OF THE FOOT
Pseudomonas has been
reported to be the most common organism causing infection following
nail puncture wounds of the foot. The treatment that produces the best
results consists of surgical drainage, debridement, and curettage of
the puncture wound in the bone, and debridement of all necrotic bone,
along with specific antibiotic therapy. The antibiotic of choice for Pseudomonas
infections is generally tobramycin, in combination with either
piperacillin or a third-generation cephalosporin, depending on the
sensitivity reports. Continue systemic antibodies for approximately 3
weeks (Fig. 133.17, Fig. 133.18).
Figure 133.17.
The plantar aspect of the foot of a 5-year-old child has swelling,
erythema, and abscess formation following a nail puncture wound to
proximal phalanx of the second toe.
Figure 133.18.
Anteroposterior radiograph of a 6-year-old child shows osteomyelitic
changes of the proximal metaphysis with involvement of the first
metatarsal phalangeal joint.
In most cases, use a plantar approach. A dorsal incision
can be used when there is joint involvement, provided that debridement
of the plantar surface of the metatarsal head or proximal phalanx is
accomplished.
Plantar or Hoffman Approach
  • Make a plantar transverse incision distal
    to the weight-bearing area of the metatarsal heads but proximal to the
    web space of the toes. Carry the incision down through the subcutaneous
    tissues and identify the flexor tendons, which should be retracted to
    expose the involved metatarsal head.
  • Incise the periosteum and elevate it to
    expose the proximal metatarsal; generally, the periosteum has been
    destroyed and this latter step is not necessary.
  • Identify the area of osteomyelitis, and
    curet and debride the lytic infected bone. If there has been extensive
    destruction of the metatarsal head, the head can be excised through
    this approach.

P.3553


Dorsal Incision
  • Make a longitudinal incision over the
    affected joint. Retract the extensor tendons. Identify the joint
    capsule and incise it longitudinally. Debride the joint of any necrotic
    tissue.
  • Next, free the soft tissue from the
    plantar surface of the metatarsal, debride any necrotic bone and
    tissue, and curet the puncture site.
  • Finally, irrigate the wound with copious amounts of irrigating fluid, and leave a small Betadine gauze or wick in the wound.
OSTEOMYELITIS OF THE METATARSAL
The metatarsals are most likely to be infected in
diabetic patients or persons who have open fractures. Depending on the
extent of the infection, local debridement of all soft tissue and bone
may be satisfactory. In more extensive infections in which the entire
metatarsal is necrotic, it may be necessary to remove it.
  • Make a longitudinal incision over the
    involved bone extending from just distal to the distal row of tarsal
    bones to the middle of the proximal phalanx of the involved toe.
  • Identify the extensor tendons and retract them.
  • Identify the involved metatarsal, incise the periosteum longitudinally, and strip it and all soft tissues from the bone.
  • Resect the entire shaft or part of the shaft as indicated. In children, avoid injury to the physis.
  • Irrigate the wound with copious amounts
    of irrigating fluid. Pack the wound loosely with a Betadine gauge or a
    fine-mesh gauze and leave a wick protruding from the wound. When the
    infection is more localized, use a smaller longitudinal incision over
    the involved metatarsal.
  • Apply a below-the-knee splint and dress the wound.
OSTEOMYELITIS OF THE CALCANEUS
Osteomyelitis of the calcaneus can be extremely
difficult to eradicate and requires adequate, thorough debridement. In
early involvement, extensive local debridement and curettage are
usually sufficient. With extensive involvement of the calcaneus,
resection of the diseased area is necessary to eradicate or control the
infection. Osteomyelitis occurring either medially or laterally in the
calcaneus usually follows pin-track infections, gunshot wounds, or open
fractures.
Medial and lateral approaches to the calcaneus are
useful in draining a localized abscess, curetting the infected bone
tissue, doing a local resection, and windowing the bone cortex for an
osteomyelitic abscess.
In osteomyelitis involving the plantar surface of the calcaneus, use the approach described by Gaenslen (15),
with modifications. Gaenslen divided the calcaneus with an osteotome
from posterior to anterior, thereby exposing the inside of the bone. He
used this technique primarily to treat hematogenous osteomyelitis.
The technique has a very serious drawback, however, in
that it creates a fracture, which could cause an infection to continue,
leading to extensive bone loss. Therefore, avoid splitting the
calcaneus when you plan to preserve it. Excision of the calcaneus
through this approach, especially when there is a wound or fistula on
the weight-bearing surface of the heel, works well.
  • With the patient prone, make a
    longitudinal incision centered in the midline of the heel. Start the
    incision just inferior to the insertion of the Achilles tendon on the
    tuberosity, and extend it plantarward approximately to the level of the
    base of the fifth metatarsal.
  • Incise the plantar aponeurosis in a plane
    between the abductor digiti quinti and flexor digitorum brevis muscles.
    Visualize the lateral plantar artery and nerve in the distal aspect of
    the wound and retract them medially.
  • Expose the quadratus plantar muscle and
    split both it and the long plantar ligament longitudinally. The plantar
    surface of the calcaneus is now exposed. For localized infection use a
    curet to remove sequestra, infected tissue, and sinuses. For more
    extensive involvement use an osteotome to resect the involved bone
    parallel to the plantar surface of the foot (Fig. 133.19). After debridement and copious irrigation, place a Betadine-soaked gauze dressing in the wound and leave the wound open.
    Figure 133.19.
    Lateral radiograph of a 42-year-old man demonstrates extensive
    destruction of the calcaneus by osteomyelitis. A marking pen outlines
    the area of bones to be resected.
  • P.3554


  • Postoperatively, change dressings daily. Permit weight bearing after the incision has healed.
OSTEOMYELITIS OF THE FIBULA
Depending on the extent of the infection, it is safe to
excise the proximal three fourths of the fibula, provided the fibular
collateral ligament and the biceps femoris tendons are inserted into
the tibia when this area of bone is sacrificed. The distal one fourth
should not be excised, because excision would lead to impaired function
of the ankle, and deformity. If it is necessary to remove this part, a
tibial–talar fusion will be necessary later.
  • Make a longitudinal incision, starting on
    the posterior border of the fibula from the head of the fibula and
    extending distalward as needed. This incision can be carried down the
    entire length of the fibula.
  • Identify the common peroneal nerve in the
    proximal part of the wound; it crosses under the peroneus longus just
    distal to its attachment to the lateral surface of the head of the
    fibula. Identify the fascial plane between the soleus muscle and the
    peroneal muscles anteriorly, and carry the dissection down to the
    fibula.
  • Retract the peroneal muscles anteriorly,
    and expose the fibula by incising the periosteum. Take care not to
    injure the branches of the deep peroneal nerve, which lie on the deep
    surfaces of the peroneal muscles at the neck of the fibula and proximal
    5 cm of the fibula. Now expose the fibula, and debride or resect the
    infected area.
  • The distal one fourth of the fibula is
    subcutaneous and can be easily exposed by a longitudinal incision along
    the posterior border of the fibula.
  • A Betadine-soaked gauze strip can be loosely placed in the wound.
  • Apply a long posterior molded splint. Dress the wound daily.
OSTEOMYELITIS OF THE PATELLA
  • Expose the patella through a longitudinal
    skin incision that starts just proximal to the patella and extends
    distally to the inferior pole. Carry the incision down through the
    subcutaneous tissue and fascia to the periosteum.
  • Incise the periosteum and elevate it with a periosteal elevator. Curette and debride the involved area of bone.
  • In cases of extensive involvement of the
    patella, either part or all of the patella can be removed. In cases in
    which the knee joint is involved, irrigate the knee with 10 L of
    irrigating fluid. Close the joint capsule over Silastic drainage tubes,
    which are removed in 48–72 hours.
OSTEOMYELITIS OF THE FEMUR
The predisposing factors leading to osteomyelitis of the
femur are very important in its management. For hematogenous
osteomyelitis, windowing of the cortex as described in this chapter is
the preferred method of treatment.

P.3555


Posterolateral Approach
  • Use either a lateral decubitus position
    or turn the patient slightly to elevate the involved extremity. This
    approach provides access to the entire femoral shaft.
  • Make an incision from the base of the
    greater trochanter distally to the lateral femoral condyle, depending
    on the desired length of exposure. Incise the superficial fascia and
    the fascia lata along the anterior border of the iliotibial band.
  • Expose the vastus lateralis muscle and
    retract it anteriorly. Continue along the anterior surface of the
    lateral intermuscular septum, which attaches to the linea aspera.
  • Expose the periosteum and incise it
    longitudinally. Then use a periosteal elevator to expose the bone.
    Debride the area of infected necrotic tissue and bone.
  • In cases of nonunion in which a plate is
    present and the infection is seen late, remove the plate and apply an
    external fixation device. Follow with an autogenous cancellous
    bone-grafting procedure when the infection is controlled.
  • In the middle third of the thigh, take
    care to identify and ligate the second perforating branch of the
    profunda femoris artery and vein, which travel transversely from the
    biceps femoris to the vastus lateralis. Avoid damaging the sciatic
    nerve and profunda femoris artery and vein by not dividing the long and
    short heads of the biceps femoris muscle.
OSTEOMYELITIS OF THE ILIUM
Infection involving the ilium can occur on the medial,
or inner, cortex and on the lateral, or outer, cortex, or on both.
Hematogenous seeding is more common in young persons. In adults,
osteomyelitis usually occurs following open fractures, bone-grafting
procedures, or, in debilitated patients confined to bed, secondary to
pressure sores.
  • Make an incision along the crest of the
    ilium extending the length of the infected area. Extend the dissection
    through the subcutaneous tissues to the crest.
  • Incise the periosteum over the top of the
    crest and subperiosteally strip the muscles from the lateral cortex of
    the iliac wing. Identify the abscess, if one is present, and the extent
    of bone involvement. Drain the abscess and debride all necrotic bone.
    Window the cortex as necessary. Be careful of the lateral femoral
    cutaneous nerve, which normally lies just medial to the anterior
    superior iliac spine. Perform local resection of the ilium for
    extensive local involvement, especially in chronic osteomyelitis (Fig. 133.20).
    Figure 133.20. A:
    Anteroposterior view of the ilium and hip showing a sinogram tract down
    to the ilium. This 44-year-old woman developed chronic osteomyelitis of
    the ilium following an open fracture. She had undergone multiple
    previous procedures. B: Radiograph after local resection of the ilium.
OSTEOMYELITIS OF THE ISCHIUM AND PUBIS
Osteomyelitis involving the ischial tuberosity is usually encountered in paraplegics or patients who are bedridden

P.3556



and develop pressure sores with secondary infection, necrosis, and
osteomyelitis. In these infections, it is necessary to debride all
necrotic tissue, after which the infected ischial tuberosity can be
resected with an osteotome and mallet. Irrigate the wound copiously and
leave it open, with Betadine-soaked gauze inserted into it to allow for
drainage. In paraplegic patients, soft-tissue transfers are often
necessary following infection control.

Abscesses in the ischiorectal fossa or beneath the
obturator externus or internus often develop with osteomyelitis of the
pubis and ischium.
OSTEOMYELITIS OF THE RADIUS AND ULNA
The ulna and the radius are most likely to become infected after open reduction and plating of fractures.
  • Because the posterior surface of the ulna
    lies subcutaneously essentially throughout its length, expose the ulna
    by a skin incision carried down through the fascia and periosteum.
  • Approach the radius in its distal third by the anterior approach, as described by Henry (24). Expose the proximal fourth of the radius with an anterior Henry incision or an extended Thompson approach.
  • The middle two thirds of the radius can then be exposed by the Thompson approach (64) (see Chapter 1).
OSTEOMYELITIS OF THE HUMERUS
In adults, osteomyelitis of the humerus most commonly
follows internal fixation of the humerus. Often, draining sinuses are
present (Fig. 133.21).
Figure 133.21.
A sinogram tract down to metal and bone. The patient had persistent
drainage for 7 months following open plating of the humerus. Notice
that the fracture is healed.
  • After assessing the extent of the infection, expose the humeral shaft through an anterolateral approach (see Chapter 1).
    Make a skin incision along the anterior border of the deltoid muscle,
    extending it distally along the lateral border of the biceps muscle to
    within several inches of the elbow joint. Identify the cephalic vein
    and ligate it.
  • Retract the deltoid laterally and the
    biceps medially to expose the proximal shaft. Distal to the deltoid
    insertion, identify the brachialis and split it longitudinally to the
    bone, retracting the lateral half laterally and the medial half
    medially. The radial nerve is protected by the lateral half of the
    brachialis muscle. In the distal third of the exposure, identify the
    radial nerve, which lies between the brachioradialis and brachialis
    muscles, and protect it. Avoid injury to the musculocutaneous nerve.
  • Debride all infected and necrotic bone
    and soft tissue. If the humerus is unstable, remove the internal
    fixation and stabalize with external fixation. Leave the wound open.
ILIZAROV PROCEDURE
In osteomyelitis, the Ilizarov procedure has been found
to be useful for the treatment of extensive bone loss problems or for
angulatory nonunions (44) (Fig. 133.22). A more

P.3557



P.3558



extensive discussion of the Ilizarov technique is presented in Chapter 32.

Figure 133.22.
Correction of deformity and subsequent healing process in a 29-year-old
man with an infected nonunion of the tibia in marked varus, treated
with the Ilizarov technique.
ACKNOWLEDGMENT
I want to thank Dr. Paul Holtom, Associate Professor of
Clinical Medicine and Orthopaedic Surgery, section of Infectious
Disease, University of Southern California School of Medicine, for his
technical assistance in the antibiotic section of this chapter.
REFERENCES
Each reference is categorized according to the following
scheme: *, classic article; #, review article; !, basic research
article; and +, clinical outcome study.
+ 1. Bach MC, Cocchetto DM. Ceftazidime as Single-agent Therapy for Gram-negative Aerobic Bacillary Osteomyelitis. Antimicrob Agents Chemother 1987;31:1605.
+ 2. Bickel WH, Bateman JG, Johnson WE. Treatment of chronic osteomyelitis by means of saucerization and bone grafting. Surg Gynecol Obstet 1953;96:265.
+ 3. Bowerman SG, Green NE, Mencio GA. Decline of Bone and Joint Infections Attributable to Haemophilus influenzae Type b. Clin Orthop 1997;341:128.
* 4. Bucholz HW, Elson RA, Heinen K. Antibiotic-loaded Acrylic Cement: Current Concepts. Clin Orthop 1984;190:96.
* 5. Bucholz HW, Engelbrecht H. Uber die Depotwirkunk Einiger Antibiotica bei Vermischung mit dem Kunstharz Palacos. Chirurgie 1970;41:511.
# 6. Canale ST, ed. Campbell’s Operative Orthopaedics, 9th ed. St. Louis, MO: CV Mosby, 1998.
+ 7. Cierney G III. Chronic Osteomyelitis—Results of Treatment. In: Green WB, ed. Instr Course Lect 1989;39:495.
* 8. Cierney G III, Mader JT, Penninck JJ. A Clinical Staging System for Adult Osteomyelitis. Contemp Orthop 1985;10:17.
+ 9. Coleman HM, Bateman JE, Dale GM, Starr DE. Cancellous Bone Grafts for Infected Bone Defects. Surg Gynecol Obstet 1946;83:392.
+ 10. Dombrowski ET, Dunn AW. Treatment of Osteomyelitis by Debridement and Closed Wound Irrigation—Suction. Clin Orthop 1965;43:215.
+ 11. Esterhai
JL, Goll SR, McCarthy KE, et al. Indium-111 Leukocyte Scintigraphic
Detection of Subclinical Osteomyelitis Complicating Delayed and
Nonunion of Long Bone Fractures: A Prospective Study. J Orthop Res 1987;5:1.
+ 12. Fitzgerald RH Jr, Ruttle PE, Arnold PG, et al. Local Muscle Flaps in the Treatment of Chronic Osteomyelitis. J Bone Joint Surg Am 1985;67:175.
! 13. Flick
AB, Herbert JC, Goodell J, Kristiansen T. Noncommercial Fabrication of
Antibiotic-impregnated Polymethylmethacrylate Beads. Clin Orthop 1987;223:282.
+ 14. Freeland AE, Mutz B. Posterior Bone Grafting for Infected Un-united Fractures of the Tibia. J Bone Joint Surg Am 1976;58:653.
+ 15. Gaenslen FJ. Split-heel Approach in Osteomyelitis of the Os Calcis. J Bone Joint Surg 193lw:759.
+ 16. Gentry LO. Treatment of Skin, Skin Structure, Bone, and Joint Infections with Ceftazidime. Am J Med 1985;79(suppl 2A):67.
+ 17. Gentry LO, Rodriguez GG. Oral Ciprofloxacin Compared with Parenteral Antibiotics in the Treatment of Osteomyelitis. Antimicrob Agents Chemother 1990;34:40.
+ 18. Gifford GB, Patzakis MJ, Ivler D, Swezey RL. Septic Arthritis due to Pseudomonas in Heroin Addicts. J Bone Joint Surg Am 1975;57:63l.
+ 19. Green SA, Dlabal TA. The Open Bone Graft for Septic Non-union. Clin Orthop 1983;180:117.
! 20. Greene
N, Holtom PD, Warren CA, et al. In Vitro Elution of Tobramycin and
Vancomycin Polymethylmethacrylate Beads and Spacers from Simplex and
Palacos. Am J Orthop 1998;27:201.
+ 21. Gristina AG, Costerton JW. Bacterial Adherence to Bio-materials and Tissue. J Bone Joint Surg Am 1985;67:264.
+ 22. Gustilo RB, Simpson L, Nixon RA, Indeck W. Analysis of 511 Open Fractures. Clin Orthop 1969;66:148.
+ 23. Harmon PH. A Simplified Surgical Approach to the Posterior Tibia for Bone Grafting and Fibular Transference. J Bone Joint Surg 1945;27:496.
# 24. Henry AK. Exposures of Long Bones and Other Surgical Methods. Brisol, UK: John Wright & Sons, 1927.
+ 25. Henry SL, Ostermann PAW, Seligson D. The Antibiotic Bead Pouch Technique: The Management of Severe Compound Fractures. Clin Orthop 1993;295:54.
+ 26. Higgs SL. The Use of Cancellous Chips in Bone Grafting. J Bone Joint Surg 1946;28:1.
* 27. Hobo T. Zur Pathogeneses der Akuten Haematogene Osteomyelitis, mit Berucksichtigung der Viratfarbungslehre. Acta Sch Med Univ Imper Kioto 1921;4:1.
+ 28. Jacobs RF, McCarthy RE, Elser JM. Pseudomonas Osteochondritis Complicating Puncture Wounds of the Foot in Children. A 10-year Evaluation. J Infect Dis 1989;160:657.
+ 29. Kelly PJ, Wilkowske CJ, Washington JA II. Musculoskeletal Infections due to Serratia marcescens. Clin Orthop 1973;96:76.
* 30. Klemm K. Die Behandlung Chronischer Knocheninfektionen mit Gentamycin-PMMA-Kugeln. Unfallchirurgie 1977;1:20.
+ 31. Klemm K. Indikation und Techhik zur Einlage von Gentamicin- PMMA-Kurgeln bei Knochen- und Wechteilinfekten. Aktuelle Probl Chir Orthop 1979;12.
+ 32. Knight MP, Wood GO. Surgical Obliteration of Bone Cavities Following Traumatic Osteomyelitis. J Bone Joint Surg 1945;27:547.
! 33. Kuechle, D.K, Landon, G.C, Musher, D.M, Noble, P.C. Elution of Vancomycin, Daptomycin, and Amikacin from Acrylic Bone Cement. Clin Orthop 1991;364:302.

P.3559


+ 34. Lexer E. Zur Experimentellen Erzeugung Osteomyelitischer Herdde. Langenbechs Arch Klin Chir 1894;48:181.
+ 35. Lister J. On the Antiseptic Principle in the Practice of Surgery. Br Med J 1867;2:246.
+ 36. Marks KE, Nelson CL, Lautenschlager EP. Antibiotic-impregnated Acrylic Bone Cement. J Bone Joint Surg Am 1976;58:358.
! 37. Marrie TJ, Costerton JW. Mode of Growth of Bacterial Pathogens in Chronic Polymicrobial Human Osteomyelitis. J Clin Microbiol 1985;22:924.
! 38. Merkel
K, Brown M, Dewanjee M, Fitzgerald R. Comparison of
Indium-labelled-leukocyte Imaging with Sequential Technetium-gallium
Scanning in the Diagnosis of Low-grade Musculoskeletal Sepsis. J Bone Joint Surg Am 1985;67:465.
+ 39. Miskew DBW, Lorenz MA, Pearson RL, Pankovich AM. Pseudomonas aeruginosa Bone and Joint Infection in Drug Abusers. J Bone Joint Surg Am 1983;65:829.
! 40. Modic MT, Pflanze W, Freiglin DH, Belhobek G. Magnetic Resonance Imaging of Musculoskeletal Infections. Radiol Clin North Am 1986;24:247.
+ 41. Murray WR. Use of Antibiotic-containing Bone Cement. Clin Orthop 1984;190:89.
+ 42. Nade S. Acute Hematogenous Osteomyelitis in Infancy and Childhood. J Bone Joint Surg Br 1983;65:109.
+ 43. Ostermann PAW, Seligson D, Henry S. Local Antibiotic Therapy for Severe Open Fractures: A Review of 1085 Consecutive Cases. J Bone Joint Surg Br 1995;77:93.
+ 44. Paley D, Catagni M, Arganani F, et al.. Ilizarov Treatment of Tibial Nonunions with Bone Loss. Clin Orthop 1989;241:146.
+ 45. Papineau
LJ, Alfageme A, Delcourt JP, Pilon BL. Chronic Osteomyelitis of Long
Bones—Resection and Bone Grafting with Delayed Skin Closure. J Bone Joint Surg Br 1976;52:138.
+ 46. Patzakis MJ, Abdollahi K, Sherman R, et al. Treatment of Chronic Osteomyelitis with Muscle Flaps. Orthop Clin North Am 1993;24:505.
+ 47. Patzakis MJ, Dorr DL, Iver D, et al. The Early Management of Open Joint Injuries. J Bone Joint Surg Am 1974;57:1065.
* 48. Patzakis MJ, Harvey JP Jr, Ivler D. The Role of Antibiotics in the Management of Open Fractures. J Bone Joint Surg Am 1974;56:532.
+ 49. Patzakis MJ, Watkins R, Harvey JP Jr. Posterolateral Bone Grafting for Infected Non-unions of the Tibia. In: Moore TM, ed. American Academy of Orthopaedic Surgeons Symposium on Trauma to the Leg and Its Sequelae. St. Louis, MO: CV Mosby, 1981:235.
+ 50. Patzakis
MJ, Wilkins J, Brien WW, Carter VS. Wound Site as a Predictor of
Complications Following Deep Nail Punctures to the Foot. West J Med 1989;150:545.
+ 51. Patzakis
MJ, Wilkins J, Kumar J, et al. Comparison of the Results of Bacterial
Cultures from Multiple Sites in Chronic Osteomyelitis of Long Bones. J Bone Joint Surg Am 1994;76:664.
+ 52. Patzakis MJ, Wilkins J, Moore TM. Considerations in Reducing the Infection Rate in Open Tibial Fractures. Clin Orthop 1983;178:36.
+ 53. Patzakis MJ, Wilkins J, Moore TM. Use of Antibiotics in Open Tibial Fractures. Clin Orthop 1983;178:31.
+ 54. Patzakis MJ, Wilkins J, Wiss D. Infection Following Intra-medullary Nailing of Long Bones. Clin Orthop 1986;212:182.
# 55. Perez-Stable EJ, Hopewell PC. Current Tuberculosis Treatment Regimens: Choosing the Right One for Your Patient. Clin Chest Med 1989;10:323.
+ 56. Perry
CR, Pearson RL, Miller GA. Accuracy of Cultures of Material from
Swabbing of the Superficial Aspect of the Wound and Needle Biopsy in
the Preoperative Assessment of Osteomyelitis. J Bone Joint Surg Am 1991;73:745.
+ 57. Rhinelander FW. Minimal Internal Fixation of Tibial Fractures. Clin Orthop 1975;107:188.
+ 58. Rissing JP. Antimicrobial Therapy for Chronic Osteomyelitis in Adults: Role of the Quinolones. Clin Infect Dis 1997;25:1327.
+ 59. Roy-Camille R, Reignier B, Saillant G, Berteaux D. Resultants de l’Operation de Papineau. Rev Chir Orthop 1976;62:347.
+ 60. Roy-Camille R, Reignier B, Saillant G, Berteaux D. Technique et Histoire Naturelle de l’Intervention de Papineau. Rev Chir Orthop 1976;62:337.
+ 61. Sapico
FL, Montgomerie JZ. Vertebral Osteomyelitis in Intravenous Drug
Abusers: Report of Three Cases and Review of the Literature. Rev Infect Dis 1980;2:196.
+ 62. Schmidt
J, Hackenbroch MH, Kumm D, Taravati V. Is Instillation Drainage for the
Treatment of Infected Joints, Bones and Soft Tissues Still up to Date? Arch Orthop Trauma Surg 1996;115:149.
+ 63. Seabold
JE, Nepola JV, Conrad GR, et al. Detection of Osteomyelitis at Fracture
Nonunion Sites. Comparison of Two Scintigraphic Methods. Am J Roentgenol 1989;152:1021.
* 64. Thompson JE. Anatomical Methods of Approach in Operations on the Long Bones of the Extremities. Ann Surg 1918;68:309.
* 65. Trueta J. The Three Types of Acute Hematogenous Osteomyelitis: A Clinical and Vascular Study. J Bone Joint Surg Br 1959;41:671.
! 66. Wahlig H, Dingledein E. Antibiotics and Bone Cements. Experimental and Clinical Long-term Observations. Acta Orthop Scand 1980;51:49.
* 67. Waldvogel
FA, Medoff G, Swartz MN. Osteomyelitis: A Review of Clinical Features,
Therapeutic Considerations and Unusual Aspects. N Engl J Med 1970;282:198, 316.
! 68. Wallenkamp G. Small PMMA Beads Improve Gentamicin Release. Acta Orthop Scand 1989;60:668.
! 69. Wallenkamp GHIM, Vree TB, Van Rens TJG. Gentamicin-PMMA Beads. Pharmokinetics and Nephrotoxicological Study. Clin Orthop 1986;205:171.
+ 70. Weiland AJ, Moore JR, Daniel RK. The Efficacy of Free Tissue Transfer in the Treatment of Osteomyelitis. J Bone Joint Surg Am 1984;66:181.

This website uses cookies to improve your experience. We'll assume you're ok with this, but you can opt-out if you wish. Accept Read More
